NCM Paris Plus
Inspired by the captivating image of the city, its creative and elegant style, the NCM Paris is one of our best-selling folding E-bike models, designed to be stylish and practical with busy city life in mind. The folding frame allows for quick and easy storage (without the use of tools) in the smallest of spaces, or packing into a car or bike case to take with you on vacation. The step-through frame takes away the chore of mounting and dismounting repeatedly when you’re running errands or need to pick the bike up over small obstacles or sidewalks. The Paris’ motor also has a unique function that allows it to run at 4mph without the need for pedalling, allowing you to navigate through heavy foot traffic or ride casually alongside someone who is walking.
Foldable handlebar stem
- Ergonomic bicycle Grips
- Confortable sitting posture
- Easy handling of the components
- Foldable bicycle handlebar stem
- All important controls easily accessible
- supplied with 36V to deliver a high output power
- over 650Wh capacity for a long distance
- reach up to 50-130 (depending on the conditions)
- Battery behind seat tube for a better balance
- easily removable battery so you can charge it anywhere
-
A built-in USB port with 5V to charge mobile phones
Front Brake:
- Reliable hydraulic disc brake system. The 160 mm Tektro brake disc ensures powerful and safe braking at all speeds.
Rear Brake:
- Reliable hydraulic disc brake system from Tektro. This brake system ensures powerful and safe braking at all speeds.
The additional power can be individually controlled via six support levels.
It is protected against dirt and splash water.
- The rear engine delivers a full torque up to 35 Nm with 250W rated power and 36V voltage.
- A large display shows all necessary settings.
- 6 support levels and a pushing aid of up to 6km/h are adjustable.
- The display's control buttons are deliberately placed on the left side - close to the left hand - so the driver can easily switch between support levels or displays without having to lift his hand off the handlebars.
Quality inspection and final adjustment:
The brand introduces itself:
NCM Bikes, founded in 2014, has quickly become one of the largest pedelec and e-bike brands in Europe with the goal of expanding the market significantly in the near future. NCM is the perfect brand to start your pedelec experience whether you are an avid cyclist or a relative newcomer, we are committed to providing you with a range of high quality.. Our innovative technologies ensure that we can differentiate ourselves from the competition and continue to offer the latest technologies. Our goal is to help improve the environment through an friendly driving experience and the promotion of a fun and active lifestyle.
NCM Paris+ 36V 19Ah Details
General Information
- Weight: 25kg (55lbs)
- Type: Folding Wheel size: 20”
- Load capacity:125kg (275lbs)
- Maximum speed: 25km/h
Battery
- Lithium-ion Battery
- Model: B1U-3619P
- Ratings: DC 36V, 19Ah, 684Wh
Electric parts
- Display: Das-Kit, C7, LCD, 6 Levels, 6km/h walk mode
- Controller: Das-Kit, CT4, 36V 14A
- Charger: Inclueded M363AU 36V 3A with XLR plug
- Motor: Das-Kit, R2S Rear-drive motor, 36V 250W, 15.5mph
- Battery: 36V 19Ah 684Wh, with USB port Average range: 50-130km depending on assistance level
- Front/Rear Light: Spanninga, KENDO, 36V, 20 Lux over bike battery / Spanninga, SOLO with 2xAA batteries
Bike parts
- Frame: Alu. 6061, 20"*380MM
- Fork: RST Carve, with suspension
- Brake Levers: Tektro, with brake sensor on both sides
- Brakes F/R: Tektro hydraulic Disc Brakes, MD-280
- Crank: Prowheel, SOLID-252AA9
- Rear Derailleur: Shimano, Acera 8-speed, RDM360
- Tyres: Schwalbe, Big Apple, 20"*2.0
- Saddle: Selle Royal, Freeway, Brown with Gel
- Seat Post: CL, PB-523, with suspension, 27.2*350mm
- Grips: Selle Royal, brown synthetic leather
- Pedals: Wellgo, foldable
Warranty
- 1 year warranty on all electronic parts (including battery, motor, controller, display, lights)
- 2 year warranty on the bike frame
- Apart from manufacture defects that could be present, parts that wear due to normal use (such as tyres, brake pads, chains, etc) are not included in the warranty but maybe replaced on a case by case basis within the first 6 months.
Disclaimer: Once you received the e-bike, we recommend to have it assembled by a professional in bike shops near you and also get your bike serviced after 1 month of use to ensure all aspects of the bike are set and calibrated correctly.
NCM Paris+ Dimensions
- Please note: These values are minimum and maximum values for the bike to be properly rideable. The bike will be most comfortable near the middle of the range indicated. The minimum value should be treated as the absolute minimum, as anything lower may result in the rider not being able to reach the pedal at the bottom of the crank cycle. Using inseam length is much more accurate and appropriate for bike sizing than height. The frame size of a bike is generally governed by the length of the seat tube.
- Using inseam length is much more accurate and appropriate for bike sizing than height. The frame size of a bike is generally governed by the length of the seat tube.
- The frame size of a bike is generally governed by the length of the seat tube.
